UNIVERSAL VLSI TRAINER KIT

Model HV-EXP5158
UNIVERSAL VLSI TRAINER KIT Indicators 10 Toggle Input Switch with LED indication to indicate logic low and logic high 10 LED for output indication. Onboard Interfaces 4 Digit Seven Segment Displays 16x1 Alphanumeric LCD Display. 4x4 Keys Keyboard Matrix. On-board ISP Programmer for Piggy Bag Modules Clock generator On-board 10MHz, 5MHz, 1MHz, 100KHz & 100Hz. Power selection On-board of 5V, 3.3V, 2.5V, 1.5V & 1.2V. I/O expansions are provided through 26 pin FRC Connector for other application interface. All ICS are mounted on IC Sockets. Made of Bare board Tested Glass Epoxy SMOBC PCB. In-Built Power Supply of +5V/1.5A, ±12V/250mA Wooden enclosures of Light weight Users Manual with 25 sample experimental programs .
