Transmission Line Trainer

Model HV-EXP1945
Technical Specifications Transmission line: Co-axial cable 100m (25mx4) Impedance Matching Resistance:- 0-100W 2 nos. Test Generators:- 1. Sine Wave 4 KHz – 4MHz 2. Square Wave 40 KHz – 4 MHz * Interconnections: 4 mm banana socket Test Points: 10 Power Supply: 220 Volt ±10%, 50Hz Power Consumption:- 3 VA approx. Accessories: Mains Cord, Set of Patch cord, Manuals, BNC – BNC cable, BNC – Crocodile clip, Multimedia interactive computer based training manual & software. Measurement with: (i) Matched (ii) Short (iii)Open end of the line (a) Measurement of line properties, Line attenuation, Freq characteristics of line, Input Impedance. (b) Measurement of stationery waves (c) Phase shift along the line (d) fault localization within the line (e) Line in pulsed condition..
