THREE-PHASE TRANSORMER

Model HV-EXP5207
THREE-PHASE TRANSORMER three-phase transformer for feeding a transmission line model, 380 kV with scale factor 1:1000. Primary: 3 x 380 V with tap at 220 V, star or delta connection. Secondary: 3 x 220 V windings with taps at +5%, -5%, -10%, -15%,star connection for 3 x 380 V, various star connections possible. Nominal power: 800 VA minimum. Tertiary: 3 x 220 V windings, delta connection for stabilizing the third harmonic voltage components, rated power: 266VA. 4 mm. safety terminal included on the front panel for the electrical connection..
