SHUNT DC MOTOR

Model HV-EXP5184
SHUNT DC MOTOR Power of 1.8 kW minimum, voltage: 220 V, speed: 3000 min-1, excitation voltage: 170 V. It must be possible to couple the electrical machine with other electrical machines through a hub and spider elastic gear ring in polyurethane. Itmust be supplied with a hooked module in aluminum with PVC label and safety terminals for the electrical connection. A schematic diagram must be shown on the hooked module. Each machine must be mounted on a base and must be provided with: - Plate that brings its axis height to the standard measure (112 mm). - Plates for fixing to the base of the machine - Four screws for fixing of the machine InterRail Distance of the plates: 160mm Coupling Joint: Diameter: 40mm, length 40mm The motor must be supplied with a theoretical and practical manual in English language..
