Refrigeration technology demonstration panel

Model HV-EXP5098
Refrigeration technology demonstration panel Hermetic piston compressor Coaxial evaporator Closed warm water circuit with tank, heater and circulating pump as cooling load Condenser with 2 fans, fan 29W each Instrumentation: bimetallic dial thermometer, manometer with temperature scale for R134a, rota meter Piston compressor: power consumption: 97W at -10/32°C, refrigerating capacity: 222W at 5/32°C Coaxial evaporator: capacity: 2kW at 45°C condensing temperature, DT=7K Measuring ranges: - pressure: -1 9bar / -1 24bar -temperature display (manometer): -6080°C - temperature: water: 2x -0100°C, refrigerant: Ix -2040°C / 3x 060°C flow rate (water): 8961tr/h, refrigerant: 1.523.51tr/h Refrigeration, unit with 2-stage switch able condenser.
