MICROCONTRLLER TRAINING KIT (LED ver.)

MICROCONTRLLER TRAINING KIT (LED ver.)

Model HV-EXP5160
MICROCONTRLLER TRAINING KIT (LED ver.) 80196KB/80196KC/8051 CPU operating at 12 MHz. 16K bytes of RAM using two nos. of 6264 with Battery Backup using NICD Battery, Memory Expandable up to 64K. 16K bytes of powerful monitor EPROM using 27512. 24 I/O lines using 8255 brought at 26 Pins FRC Connector to interface with IC-XX Series. RS-232c interface using Rx/Tx. Eight Digital Seven Segment Display with 25 Keys hex keyboard using 8279. On-chip 8 Channel 10 bit ADC. On-chip PWM. On-chip High speed I/O. On-chip Interrupt. Two modes of operation: Keyboard Mode. Serial Mode. Cross assembler software for 80196. Powerful Commands like Examine/Edit Memory, Examine/Edit Register, Single stepping, Execution can be used through hex keyboard or PC serial mode. Facility for Downloading/Uploading files from/to PC. All Address, Data, Control & Port lines are available on 40 Pins & 20 Pins FRC Connector. All ICS are mounted on IC Sockets. Made of Bare board Tested Glass Epoxy SMOBC PCB In-Built Power Supply of +5V/1.5A, ±12V/250mA Wooden enclosures of Light weight Wood. Users Manual with more than 10 sample programs .
