KIT FOR STUDYING FIBRE OPTICS

Model HV-EXP2431
KIT FOR STUDYING FIBRE OPTICS This kit is designed to study the behaviour of light in fibre optics, the applications in data transmission, examples of sensors used with fibre optics. COMPONENTS • Data transmission card • Data reception card • Analog transmitter / receiver • Digital transmitter / receiver • Transmitter with microphone • Receiver with loudspeaker • Frequency generator • RS232 converter with receiver and transmitter TRAINING PROGRAM • Detecting signals via an analog receiver • Tyndall’s experiment • Transmitting a signal via a function generator • Transmission and amplification of sound, transformation of sound into electric signal, optical pulse, and their back conversion • Examples of optical sensors (level sensor, force sensor, photogate) • Optical transmission between PCs
