Heat transfer in refrigeration system

Model HV-EXP5069
Heat transfer in refrigeration system Model of a refrigeration system with closed water circuit that is used as a cooling load Hot water circuit with tank, heater, pump and temperature controller Hermetic piston compressor Coaxial evaporator and condenser Heater 300W Sight glass in the refrigerant circuit Instrumentation: bimetallic thermometers and rota meters Refrigerant R 134a Compressor: power consumption: 150W at -10°C, Refrigerating capacity: 280W at 0/32°C Coaxial tube heat exchanger: capacity: 2kW at 45°C condensing temperature, DT=7K Circulating pump, 3 stages: 30-45-60W, Max. Flow rate: 2.9mVh, Max. head: 4m Heater 300W Insulated water tank: 4.51tr.
