Analog Communication Trainer

Model HV-EXP1957
Specifications: It demonstrate AM, FM & PM (Phase Modulation) Modulation and Demodulation techniques.. On-Board synchronized Source. Various test points provided on-board with comprehensive instruction manual. Inbuilt power supply Assembled in ABS plastic box with cover Set of patch chords & users manual Trainer demonstrates the principle of Amplitude Mod. & Demod. Built - in IC based DC regulated power supply On-Board Audio Oscillator 100Hz to 10KHz. Amplitude Modulation. Double Sideband AM Generation. Single Sideband AM Generation (USB/ LSB). O/P Amplifier Audio Pre-Amplifier. Ceramic Filter. & On- Board Antenna. It would also demonstrate Frequency Modulation & Demodulation and also demonstrate Phase Modulation and Demodulation FM Modulator: 1.Varactor Modulator, 2.FMvia PM. PM Modulator..
