8- Bit PIC Micro Controller Trainer kit

Model HV-EXP5169
8- Bit PIC Micro Controller Trainer kit 16F877 PIC Microcontroller. On Board ICD Compatible. On Board Serial Port to Communicate with PC Operates on 4 MHZ Crystal Frequency. Provision to Connect Keypad, Elevator, Display, ADC, DAC, 8-bit 16 Channel ADC, Logic controller, Tone generator, Stepper motor, Opto Isolated input/output card, Relay output, DC Motor, RTD Interfaces. On board 6 digit 7 segment Display. On board 10 bit, 16.47 μs, 8 channel ADC from 16F877 MCU. Operating Speed: DC 20MHZ Clock input. DC: 200ns instruction cycle. Eight level deep Hardware stack, Power on Reset, Power up timer and Oscillator start-up Timer, Watching Timer, Programmable Code Protection, Power Saving SLEEP MODE, In circuit serial Programming via two Pins. Processor read/write access to Program, Power Supply and IDE Software. User Manual .
