Split Phase AC Motor

Model HV-EXP2271
These motors belong to the Single phase motor family, but these do not have capacitors to provide the initial turning effect, and hence have avery low starting torque. This Model is the Industrial/Educational model suitable for demonstrating to students the complete know of the Basics, Starting method, Winding study, Study of Speed-Torque, Study of Efficiency & Maintenance of these motors packaged in small rating.Students can make connections of their own with the help of the terminations provided. Technical Specs : Power ratings available :1KW /2KW Voltage Input: 230V AC 1Phase 50Hz 1500 rpm, Class-B, S1, Single /Double shaftextension List Of Experiments Starting by DOL Starter Starting by reduced voltage starter. Load test & No load test of machine Speed-Torque Analysis Voltage-Speed Analysis Efficiency Analysis Blocked rotor test Cold Resistance & Hot Resistance Motor Operation parameters Basic Overhauling Know how.
